SOCO SCM600-PRO

The SCM600-PRO serves practices that want to analyse cases, not only record them. In endodontics, image-to-image comparison places a pre-operative view beside the post-operative result, showing the completeness of access, canal location and obturation. Measurement tools let the clinician size a perforation, a crack line or a lesion on screen and record the figure in the patient's notes.

Periodontal and implant care benefit from comparisons over time. A stored image of the gingival margin or peri-implant tissue can be set against live video at a review appointment, so changes in recession, inflammation or healing are seen directly. Restorative dentists compare preparation stages and check finished margins, and the orange and green filters support resin work and soft tissue visualisation.

Patient communication becomes easier with live output. Real-time 1080p video at 60 frames per second runs to a chairside display over HDMI, and dual-mode USB and Type-C transfer lets images move to a smartphone for a patient or a referring colleague. Key steps are recorded and saved for later analysis and discussion, supporting teaching, documentation and remote consultation.

Its users include endodontists, periodontists, implant dentists, restorative specialists, referral practices and teaching clinics. The two-stage locking swivel arm and locking balance arm keep the view steady while images are captured, and the compact 590 × 590 mm base suits surgeries with limited space. Practices that review treatment outcomes regularly or present cases to patients and colleagues will put the comparison and measurement tools to daily use, building a visual history for every patient they treat.

Analysis, Not Just Recording

Built-in image comparison and measurement turn recordings into clinical information. Progress and dimensions are checked on screen.

Before and After, Side by Side

Image-to-image and image-to-live-video comparison show change directly. Review appointments gain a visual reference.

Clear Images in Mixed Light

Wide dynamic range balances reflective enamel and dark canals in one frame. Detail stays readable across the image.

Smooth Live Video

1080p at 60 frames per second gives fluid motion with low latency. Patients and assistants follow procedures in real time.

Files Straight to a Phone

Dual-mode USB and Type-C ports connect to smartphones and other devices. Sharing images takes moments.

Hands-Free Capture

The wireless foot switch captures photos and video. It can sit wherever the clinician's foot falls.

Works With Existing Screens

Plug-and-play HDMI and USB output connects to standard displays and recorders. Current equipment stays in use.

A Locked, Steady Field

Locking swivel and balance arms hold the view while images are captured. Comparisons start from consistent framing.

Built-In HD Imaging System

An integrated HD platform captures and transmits each step in real time. It comes as standard on the SCM600-PRO.

4-in-1 Camera Module

A 45° extender, pendulum system, beam splitter and camera system are combined in one unit. The split ratio is 2:8 or 5:5.

High-Performance CMOS Sensor

The sensor gives clear, natural-colour imaging. Output reaches 1,920 × 1,080.

1080p at 60 Frames Per Second

Live output runs at 60 frames per second. Motion stays fluid, with no blur.

Wide Dynamic Range

WDR balances highlights and shadows. Bright and dark areas both hold detail.

Optimised Image Engine

Low latency, accurate colour and sharp edges come from the processing engine. The screen keeps pace with the procedure.

Image Comparison and Measurement Software

The imaging management system compares image to image, image to live video, and measures on screen. Analysis happens at the chairside.

4K Wireless Foot Pedal Component

The wireless foot switch captures photos and video on demand. The USB module supports USB 3.0 storage and wireless mouse operation.

Dual-Mode USB and Type-C Interface

Plug-and-play ports connect to smartphones and other devices. Images can be viewed off the microscope immediately.

HDMI and USB Output

Output connects plug-and-play to standard displays and recorders. Monitors from 24-inch HD to 27-inch 4K UHD are optional.

Nano-Coated Apochromatic Optics

German-imported multi-layer nano-coated lenses give sharp, colour-true images. A five-step zoom spans 1.8× to 19.1×.

65,000 Lux LED Illumination

True-colour LED light at 5,700 K with a CRI above 90 lights eyepieces and camera alike. Orange and green filters are built in.

Locking Swivel and Balance Arms

A two-stage swivel lock and a locking balance arm hold position. The balance arm rotates through 320° with 480 mm of vertical travel.

The SCM600-PRO is the microscope for practices that want to understand their cases as well as record them. Its built-in 1080p imaging, running at 60 frames per second with wide dynamic range, feeds software that compares images, sets stored views against live video and measures on screen. The 4K wireless foot pedal captures hands-free, and USB 3.0 and Type-C ports move files straight to a phone or computer. Nano-coated apochromatic optics, a five-step 1.8× to 19.1× zoom and locking arms keep the view clear and steady. Endodontists, periodontists, implant dentists and teaching clinics that review outcomes will use its analysis tools every day.
