Roundfin XH-2016 Tissue Floating Bath

NHS histopathology departments, hospital pathology laboratories, and specialist diagnostic services that require a complete post-microtomy slide-preparation station in a single, compact instrument are the primary procurement context for the Roundfin XH-2016 Tissue Floating Bath. By combining the XH-1003's chemical-resistant glass tray tissue-floating bath with the XH-2003 slide warmer in a single integrated unit, the XH-2016 provides the complete tissue-section flotation and slide-warming workflow from a single 35 cm × 35 cm bench-top footprint — eliminating the need for two separate instruments and two separate bench positions. Medigear.uk supplies the XH-2016 and can provide NHS procurement documentation.

Cancer diagnostic centres, surgical pathology services, and specialist staining laboratories benefit from the XH-2016's chemical-resistant glass tray bath — inherited from the XH-1003 — which provides a transparent, chemically durable working surface for tissue section flotation. The 1–240 minute timer on the slide warmer section enables flexible timed warming cycles suited to diverse IHC and staining protocols. Medigear.uk can advise on XH-2016 configuration for specialist diagnostic settings.

Medical colleges, university histology departments, and teaching hospitals benefit from the XH-2016's single-station design, which provides a compact, clearly organised working platform that demonstrates the complete post-sectioning slide-preparation workflow — from section flotation at 65°C as a default through to timed slide warming — in a single teaching instrument. The 40-slide warmer capacity accommodates typical class-size batches. Medigear.uk can advise on the procurement of XH-2016 for medical education settings.

Research histology laboratories, food testing facilities, and private pathology services will find the Roundfin XH-2016 available through Medigear.uk. The combined station design and dual-voltage AC120V/220V specification support diverse deployment contexts, and the 90°C upper warmer temperature with 1–240min timer flexibility meet varied research and specialist staining protocol requirements. Medigear.uk can discuss XH-2016 supply terms on request.

Single Station — Bath and Warmer in One Compact Unit

The XH-2016 consolidates the XH-1003 tissue floating bath and XH-2003 slide warmer into a single 35×35cm instrument, replacing two separate bench positions with a single integrated post-microtomy slide-preparation station. For NHS departments and laboratories managing bench space, this single-station design simplifies workflow organisation and reduces the equipment footprint without compromising the capabilities of either instrument.

Chemical-Resistant Glass Tray from the XH-1003

The chemical-resistant glass tray, inherited from the XH-1003 Tissue Floating Bath, provides a transparent, chemically durable flotation surface with interior dimensions of 210×165×55 mm. The glass resists degradation by the chemicals used in tissue-processing workflows. It provides direct visual inspection of section spreading from above and from the side — a capability not available with opaque or coated metal tray designs.

1–240 Minute Timed Warming — Unique in the 2-in-1 Range

The 1- to 240-minute timer on the XH-2003 slide warmer section provides timed warming protocol control that is not available on the FL-220 or RD-86 combination instruments. This timer enables the operator to set a specific warming duration from 1 minute to 4 hours, supporting diverse protocol requirements, including IHC pre-treatment warming, section adhesion warming, and protocol-specified timed warming before staining.

65°C Default Bath Setting

The 65°C factory-default bath temperature provides a ready-to-use starting point for standard paraffin section flotation without requiring manual temperature entry at each session start — a practical feature that reduces setup time and eliminates the risk of incorrect temperature entry in the most common daily protocol.

40-Slide Warmer Capacity

The XH-2003 warmer section's 40-slide maximum capacity supports standard diagnostic batch sizes in routine histopathology workflows, accommodating the number of sections typically processed from a single specimen or a small-batch teaching session.

Room Temp to 90°C Warmer Range with ±2°C Accuracy

The 90°C upper warmer with ±2°C accuracy provides full coverage of specialist warming protocols, including high-temperature IHC pre-treatment and adhesion enhancement applications. At the same time, the ±2°C precision maintains consistent conditions throughout the warming session.

Low-Profile 10cm Height — Space-Efficient Bench Placement

At only 10cm instrument height within a 35×35cm footprint, the XH-2016 is one of the lowest-profile combination tissue preparation instruments in the Roundfin range. This flat, compact form allows positioning beneath overhanging storage, adjacent to tall instruments, and in space-constrained histopathology workstation layouts.

Dual Voltage AC120V/220V for Flexible Deployment

AC120V 50Hz and AC220V 50Hz dual-voltage support enables deployment across a range of international electrical environments, facilitating export supply and cross-border procurement for research, commercial, and institutional buyers. Medigear.uk can confirm voltage compatibility and supply terms on request.

Combines XH-1003 Tissue Floating Bath + XH-2003 Slide Warmer

An explicitly manufacturer-described combination of two named Roundfin instruments into a single integrated station.

Chemical-Resistant Glass Tray: 210×165×55mm

Transparent, chemically durable flotation surface. Direct visual inspection from above and sides.

Bath Temperature: Room Temp to 70°C, ±2°C

The default setting is 65°C for standard paraffin section flotation. Adjustable by the operator.

Slide Warmer Temperature: Room Temp to 90°C, ±2°C.

Full-range warming from ambient to 90°C. Covers IHC and specialist staining protocols.

Timer: 1–240 Minutes

Flexible timed warming from 1 minute to 4 hours. Unique timer feature in the Roundfin 2-in-1 range.

Slide Warmer Capacity: 40 Slides

Standard diagnostic batch capacity. Suits routine histopathology and teaching workflows.

Power: 450 Watts

Combined dual-zone bath and warmer power. Supports simultaneous operation of both zones.

Dimensions: 35cm×35cm×10cm; 8.6kg

Square footprint, ultra-low 10cm profile. One of the most compact combination stations in the range.

Voltage: AC120V/220V 50Hz

Dual voltage for flexible international deployment. Contact Medigear.uk to confirm supply.

Default Bath Setting: 65°C

Factory pre-set for immediate use at standard paraffin flotation temperature.

Humidity: <80%

Standard laboratory ambient humidity specification.

1-Year Warranty + Lifetime Technical Support

Supplied through Medigear.uk with warranty and ongoing technical access.

The Roundfin XH-2016 Tissue Floating Bath is a 2-in-1 tissue floating bath and slide warmer station combining the XH-1003 chemical-resistant glass tray bath and the XH-2003 Step Up slide warmer, suited to NHS histopathology departments, hospital pathology laboratories, cancer diagnostic centres, medical colleges, and research histology services requiring a complete post-microtomy slide preparation station with chemical-resistant glass tray flotation, 40-slide timed warming with 1–240 minute timer, room temperature to 70°C bath zone, room temperature to 90°C warmer, 450W power, and dual voltage AC120V/220V support in a compact 35×35×10cm bench-top footprint. Contact Medigear.uk for full specifications, pricing, or expert procurement assistance.
