Roundfin RF-3000A Slide Stainer

Robotic Arm. Servo Motion Control. 30-Slide Staining. 120-Slide Coverslipping. 100+ Programs. Exhaust Purification.

The Roundfin RF-3000A is a fully automatic slide stainer and glass coverslipper workstation for histopathology laboratories, featuring a high-speed robotic arm, servo motion control, a reagent heating system, more than 100 programmable staining protocols, 30-slide staining throughput, 120-slide coverslipping throughput, exhaust gas purification, and a dual sound-and-light alarm system. Available through Medigear.uk.

Sections

Microtomes

Categories

Lab, Pathology & Blood Bank

Condition

New

Origin

China

Seller Type

Certified Professional Seller

CE & ISO Certified

Global Shipping

Supplier: Medigear

The Roundfin RF-3000A is a fully automatic slide stainer and glass coverslipper workstation designed for histopathology laboratories, delivering consistent staining quality with a fully automated workflow from staining through to coverslipping. The slide stainer integrates a high-speed robotic arm for handling and transporting slide racks, a servo motion control system for short running time and staining quality comparable to manual operation, and a reagent heating system that eliminates seasonal effects on staining consistency. Medigear.uk supplies the RF-3000A and can advise on configuration and installation.

The slide stainer has 28 total stations (2×13 tank positions) with a reservoir volume of 480±20 ml. Slide rack capacity is 30 pcs, and throughput is 30 pcs per run. Programme storage capacity is 100 or more programs. The oven station temperature reaches a maximum of 75°C, and the reagent heating station reaches a maximum of 60°C. Instrument dimensions are 1073×667×651 mm (W×D×H) with a net weight of approximately 135 KGS. Rated power is 1200W at 220V AC, 50Hz. Operating temperature range is 5°C–70°C.

The glass coverslipper processes up to 120 slides per run and has a coverslip box capacity of 350 pcs. Cover slip size is 24×(50+10)mm, and slide size is 26×75mm. Sealant bottle volume is 230 ml. Water tank temperature range is 0–70°C. Instrument dimensions are 849×733×651 mm (W×D×H). Rated power is 1000W at 220V AC, 50Hz. The relative humidity operating range is 10%–80%.

Both units incorporate automatic monitoring of exhaust gas concentration and a purification device. Both are equipped with dual sound and light alarm systems for operational failures, pausing automatically until the fault is resolved to protect the slides. The coverslipper additionally includes automatic cover glass breakage detection, intelligent debris handling, and cover slip margin monitoring with intelligent alerts. We can provide the full specification and supply terms on request.

NHS histopathology departments, hospital diagnostic laboratories, and high-volume pathology services that require fully automated slide staining and coverslipping are the primary procurement context for the Roundfin RF-3000A. The integrated workstation eliminates the manual handoff between staining and coverslipping, and its 30-slide staining throughput, combined with 120-slide coverslipping capacity, supports demanding daily specimen volumes. The programme's storage capacity of more than 100 enables validation of the full range of staining protocols required by a busy diagnostic histopathology department. Medigear.uk supplies the RF-3000A and can provide NHS procurement documentation.

NHS cancer diagnostic centres, specialist surgical pathology services, and cytology laboratories benefit from the servo motion control system, which produces staining quality comparable to manual operation — the key quality benchmark for diagnostic histopathology where staining consistency directly affects diagnostic confidence. The reagent heating system eliminates seasonal variability, ensuring consistent results year-round without protocol adjustments. Medigear.uk can advise on the RF-3000A configuration for specialist diagnostic applications.

Research institutions and medical school histopathology departments benefit from the RF-3000A's large programme storage capacity and flexible protocol design, supporting varied and non-standard research staining requirements alongside routine diagnostic protocols. The automated exhaust gas purification on both units supports safe operation in shared research laboratory environments where solvent exposure is a health and safety consideration. Medigear.uk can advise on the procurement of the RF-3000A for research and educational settings.

Private pathology laboratories and commercial histopathology services requiring high-throughput automated staining and coverslipping with minimal manual intervention will find the Roundfin RF-3000A available through Medigear.uk. The dual-alarm system with automatic pausing protects slides during any fault condition, ensuring reliable operation in commercial laboratory workflows. Medigear.uk can discuss RF-3000A supply terms on request.

Integrated Staining and Coverslipping Workflow in a Single Workstation

The RF-3000A combines a fully automatic slide stainer and a fully automatic glass coverslipper in a single coordinated workstation, eliminating the manual handoff between separate staining and coverslipping instruments, which introduces handling risks, time delays, and workflow inefficiencies. After staining is complete, slides proceed to coverslipping, and once sealed, they are immediately ready for filing without further processing — supporting a seamless, operator-light workflow from stained rack to filed, labelled slide.

High-Speed Robotic Arm for Consistent Rack Handling

The high-speed robotic arm handles and transports slide racks throughout the staining process, providing consistent, repeatable rack positioning across all stations that eliminates the variability introduced by manual rack handling. The robotic arm's speed also supports short total run times, maximising daily throughput within the 30-slide-per-run stainer design.

Servo Motion Control for Manual-Comparable Staining Quality

The servo motion control system is specifically designed to ensure staining quality comparable to manual operation — the most rigorous quality benchmark for an automated stainer, since manual staining by an experienced histotechnician remains the reference standard in diagnostic histopathology. The servo system's precise positional and speed control supports consistent reagent contact time and transition speed across all slides and all stations.

Reagent Heating System for Year-Round Consistency

The reagent heating system maintains controlled reagent temperatures throughout the staining process, eliminating seasonal variability in staining quality caused by ambient temperature changes across different times of day, seasons, and laboratory environments. For laboratories that have previously experienced staining protocol drift requiring seasonal adjustment, the RF-3000A's heating system provides a direct operational quality improvement.

100-Plus Program Storage for Full Protocol Library Management

The programme storage capacity of 100 or more validated staining programs supports the full range of routine diagnostic staining protocols, as well as specialist, research, and non-standard protocols, within a single instrument's memory. For busy diagnostic departments with diverse staining requirements, this eliminates the need to reprogram or revalidate protocols when switching between stain types, reducing protocol management workload and supporting the ready-to-run availability of all validated protocols.

Automatic Exhaust Gas Monitoring and Purification on Both Units

Both the slide stainer and the glass coverslipper incorporate automatic monitoring and purification of exhaust gas concentrations, managing solvent vapour exposure at the source rather than relying entirely on laboratory ventilation infrastructure. This active purification supports safe operation in existing laboratory spaces, reduces the minimum ventilation specifications for installation, and provides real-time environmental monitoring without requiring manual air sampling.

Cover Glass Breakage Detection and Intelligent Debris Handling

The coverslipper's automatic detection of cover glass breakage, along with intelligent debris handling, addresses one of the main failure modes of automated coverslipping — broken cover glasses that create debris that can damage subsequent slides or contaminate the instrument. The automatic detection and handling system manages breakage events without manual intervention, maintaining operation through minor breakage events while alerting the operator to sustained issues via the dual alarm system.

Dual Alarm System with Automatic Safe Pause

Both units' sound-and-light dual-alarm systems automatically pause operation when a fault is detected, preventing processing from continuing under a fault condition that could damage slides or produce non-diagnostic sections. This safe-failure design supports confident unattended or minimal-attendance operation throughout the working day, as slide batches are protected from fault-induced damage without requiring constant operator supervision.

Fully Automatic Slide Stainer

High-speed robotic arm for handling and transporting slide racks. Servo motion control for manual-comparable staining quality. Reagent heating eliminates seasonal variability.

Fully Automatic Glass Coverslipper

120 slides per run throughput. 350 pcs cover slip box capacity. Slides are ready for filing immediately after sealing.

28 Tank Station Configuration

2×13 tank positions. 480±20 ml reservoir volume. Supports parallel multi-program staining runs.

100+ Program Storage

Full diagnostic staining protocol library management in a single instrument. Ready-to-run validated programs without reprogram requirements.

Exhaust Gas Purification (Both Units)

Automatic exhaust-gas concentration monitoring and purification on the stainer and coverslipper—safe, eco-friendly operation.

Cover Glass Breakage Detection

Automatic detection and intelligent debris handling. Cover slip margin monitoring with intelligent alerts.

Dual Alarm Safety System (Both Units)

Sound and light alarm with automatic pause on operation. Protects slides during fault conditions without manual supervision.

Reagent Temperature Control

Oven station max. 75°C. Reagent heating station max. 60°C. Eliminates seasonal staining variability.

Multiple Parallel Program Execution

Multiple dyeing programs run concurrently—Maximises throughput for diverse slide types and staining protocol requirements.

Servo Motion Control

Precise positional and speed control for short run time and consistent reagent contact across all slides and stations.

Stainer Dimensions: 1073×667×651mm

Approx. 135KGS. 1200W, AC220V 50Hz. Operating temperature 5°C–70°C.

Coverslipper Dimensions: 849×733×651mm

1000W, AC220V 50Hz. Humidity 10%–80%. 230ml sealant, 350 pcs cover slip box.

The Roundfin RF-3000A is a fully automatic slide stainer and glass coverslipper workstation suited to NHS histopathology departments, hospital diagnostic laboratories, cancer diagnostic centres, specialist pathology services, research institutions, and commercial histopathology services requiring high-throughput automated slide staining and coverslipping with servo motion control, robotic arm rack handling, reagent heating, 100-plus stored staining programs, exhaust gas purification, and comprehensive slide protection across the staining and coverslipping cycle. Its 30-slide staining throughput, 120-slide coverslipping capacity, automated cover glass breakage detection, cover slip margin monitoring, and dual alarm safety systems deliver a reliable and complete histopathology automation solution from staining through to filing. Contact Medigear.uk for specifications, pricing, or expert procurement assistance.

FAQ

Frequently Asked Questions

Everything buyers need to know about sourcing medical equipment through MediGear.

The RF-3000A is an integrated workstation comprising two fully automatic instruments: the RF-3000A Fully Automatic Slide Stainer and the RF-3000A Fully Automatic Glass Coverslipper. The slide stainer performs the fully automated staining workflow, including reagent immersion, washing, and drying, across 28 tank stations using more than 100 stored staining programs. The coverslipper then automatically seals the stained slides with cover glasses, leaving them ready for immediate filing. Together, the two units automate the complete slide-preparation workflow, from staining through to coverslipped, filed sections.

The slide stainer processes 30 slides per run using a high-speed robotic arm for slide rack handling and transport. The 28 total stations (2×13 tank positions) support concurrent staining at multiple protocol stages, and the servo motion control system is designed to minimise run time while maintaining staining quality comparable to manual operation. The programme storage capacity of 100 or more programs supports a large validated staining protocol library for diverse diagnostic and research applications.

The glass coverslipper has a sample slide throughput of 120 pcs per run, a coverslip box capacity of 350 pcs, and a sealant bottle volume of 230 ml. After coverslipping, slides can be placed directly on the slide board and are ready for filing immediately after diagnosis, with no additional handling or waiting required. The cover slip size is 24×(50+10)mm, and the slide size is 26×75mm, covering standard histopathology slide and cover glass formats.

The reagent heating system maintains reagents at controlled temperatures during staining, eliminating variability in reagent viscosity and chemical reaction rates caused by seasonal and diurnal temperature fluctuations. Without a reagent heating system, staining quality can vary between summer and winter or between morning and afternoon sessions; the RF-3000A's heating system eliminates this variability, supporting consistent staining outcomes throughout the working year without protocol adjustment.

Both the slide stainer and the glass coverslipper incorporate automatic monitoring of exhaust gas concentration and a purification device. The system monitors solvent vapour concentrations and purifies exhaust gases before release, supporting safe and eco-friendly laboratory operation in line with workplace solvent exposure standards. This automatic monitoring and purification eliminates the need for manual exposure monitoring and reduces the ventilation infrastructure requirements for the instruments.

Both the slide stainer and the coverslipper are equipped with dual sound and light alarm systems that alert the operator to operational failures. When an alarm is triggered, the system automatically pauses operation until the fault is identified and resolved, protecting slides from damage that could occur if processing continued through a fault condition. This safe-failure design means slides are never lost to undetected processing errors during unattended or minimal-attendance operation.

The glass coverslipper includes automatic detection of cover glass breakage during coverslipping, with intelligent debris handling that manages broken glass fragments without manual intervention. Cover slip margin monitoring with intelligent alerts notifies the operator when cover slip placement deviates from the specified margin parameters, supporting consistent cover glass positioning across all slides without manual inspection of each coverslipped slide.

Yes — the slide stainer supports multiple dyeing programs running in parallel, enabling simultaneous processing of different staining protocols across the 28-tank station configuration. This parallel processing capability is essential for high-throughput diagnostic laboratories, where multiple slide types and staining protocols must be processed concurrently within the working day, without the throughput limitations of a sequential single-protocol approach.

Safety features across both units include automatic exhaust gas monitoring and purification for safe solvent management, a sound and light dual alarm with automatic pause for fault protection, automatic cover glass breakage detection with debris handling, and servo motion control for precise, controlled instrument operation. Together, these systems support safe, reliable, largely unattended operation of the staining and coverslipping workflow throughout the working day.

Yes — the RF-3000A is supplied by Medigear.uk and is available for NHS procurement. Specification sheets, configuration documentation, and system information for governance review are available from the Medigear.uk team. The RF-3000A's combination of high throughput, 100-plus programme capacity, automated exhaust management, and comprehensive safety systems aligns with the operational requirements of NHS histopathology departments. Medigear.uk can discuss NHS procurement terms and lead times on request.
