Visionstar HV-300

Seven Working Modes

Four monopolar cutting modes, two monopolar coagulation modes and one bipolar mode are each listed with their own rated load, output ceiling, peak voltage and crest factor.

Pure Cut to 400W

Pure cutting is listed at 500 ohms rated load, 400W maximum output, 1900V peak to peak and a typical crest factor of 1.6, the highest cutting power of the seven modes.

Three Graded Blend Levels

Blend 1 is listed at 250W and 2300V, Blend 2 at 200W and 2500V, Blend 3 at 150W and 2800V, with crest factors rising from 2.5 to 2.9 as power falls.

Fulgurate Coagulation

Fulgurate is listed at 500 ohms rated load, 120W maximum output, 2800V peak to peak and a typical crest factor of 2.9.

Spray Coagulation

Spray is listed at 500 ohms, 100W, 7000V and crest factor 6.2, giving the highest peak voltage and the most interrupted waveform on the console.

Bipolar Coagulation

Bipolar standard coagulation is listed at 100 ohms rated load, 70W maximum output, 550V peak to peak and a typical crest factor of 1.6.

Return Electrode Monitoring

The manufacturer describes a contact quality monitoring system watching patient impedance and deactivating the generator when a contact fault is detected.

Compatibility and Interface

Argon plasma coagulation equipment, a smoke evacuation system and an underwater cut socket for endoscopic cutting are all listed, with several selectable interface languages.

Graduated Cutting

Four cutting modes give a progression rather than a choice between two settings. Pure cut at 400W and crest factor 1.6 is the cleanest waveform, and each blend step raises crest factor and lowers power, moving the effect toward haemostasis. A surgeon can therefore match the setting to the tissue and the bleeding they expect. Which mode suits a given case is entirely a surgical judgement that no listing should attempt to inform.

Two Approaches to Monopolar Haemostasis

Fulgurate at 120W and 2800V and spray at 100W and 7000V behave quite differently despite similar power figures, and the crest factors of 2.9 and 6.2 are where that difference shows. Spray in particular reaches the highest peak voltage on the console. Having both available means a team is not forced to approach every bleeding surface the same way, which matters where tissue and access differ across a list.

Bipolar Working

Bipolar standard coagulation runs at 100 ohms rated load with 70W and 550V. Bipolar working confines current between the forceps tips rather than passing it through the patient to a return electrode, which is why it is commonly wanted alongside monopolar modes on the same console for the parts of a list where that matters.

Endoscopic and Cross Specialty Work

An underwater cut socket for endoscopic cutting is listed, which bears directly on the transurethral resection named in the manufacturer's application list. That list also spans general surgery, gastroenterology, vascular, obstetric and gynaecological, thoracic, ENT, neurological, orthopaedic and plastic work, indicating a general purpose console rather than one built for a single discipline, which suits a shared theatre.

A Genuinely Graded Cutting Range

Three blend levels between pure cut and coagulation is more than most consoles publish, and the figures show a real progression rather than nominal steps: power falls from 250W to 150W while crest factor climbs from 2.5 to 2.9 and peak voltage rises from 2300V to 2800V. That gives a surgeon somewhere to go when pure cutting bleeds more than they want and full coagulation is more than the tissue needs, without changing instrument.

Every Mode Published in Full

Rated load, maximum output power, maximum peak to peak voltage and typical crest factor appear for all seven modes. Output power quoted without the impedance it was measured into is close to meaningless for comparison, and crest factor is what actually distinguishes one waveform from another. A biomedical department can set these figures against an existing unit and reach a reasoned conclusion rather than an impression.

Breadth Without a Second Console

Seven modes spanning cutting, two forms of monopolar coagulation and bipolar work, with stated compatibility for argon plasma equipment, smoke evacuation and an endoscopic cut socket, cover a wide range from one console. For a theatre whose list changes through the week, that avoids either compromising on capability or finding space and budget for a second generator standing beside the first.

The Visionstar HV-300 is a seven mode diathermy console published mode by mode. Pure cut reaches 400W into 500 ohms at 1900V with crest factor 1.6; Blend 1, 2 and 3 run at 250W, 200W and 150W with peak voltages of 2300V, 2500V and 2800V and crest factors from 2.5 to 2.9; fulgurate delivers 120W at 2800V; spray delivers 100W at 7000V with crest factor 6.2; and bipolar standard coagulation gives 70W into 100 ohms at 550V. Main frequency is 512 KHz, return electrode monitoring runs throughout, and weight is listed at 8.00kg.

Several things are deliberately absent. The electrical supply figures and the leakage measurements printed on the card are not reproduced, since these are tested characteristics a supplier should confirm rather than a listing assert, and the named smoke evacuation system is likewise omitted. The dimension figures carry no unit on the card and appear here as printed. Nothing here should be read as a claim about testing or regulatory approval.
