Visionstar KJ5S3

Home
Shop
ENT, Ophthalmic & Sensory
Visionstar KJ5S3

✓ Certified Professional Seller

Visionstar ENT, Ophthalmic & Sensory

Visionstar KJ5S3

Portable Slit Lamp with Camera. 10X and 16X. White LED. Rechargeable Battery. Four Spot Sizes. Four Filters. Domiciliary and Outreach.

The KJ5S3 Portable Slit Lamp is a portable converging slit lamp with camera attachment for anterior segment imaging and clinical documentation, featuring 10X and 16X magnification, white LED illumination, rechargeable 7.2V Li battery, four filter spot sizes (1mm, 3mm, 5mm, 10mm), heat-absorption, grey, red-free and cobalt blue filters, and 0–10mm continuously adjustable slit width. Available through Medigear.uk.

Sections

Slit Lamps

Categories

ENT, Ophthalmic & Sensory

Condition

New

Origin

China

Seller Type

Certified Professional Seller

CE & ISO Certified

Global Shipping

Supplier: Medigear

The KJ5S3 Portable Slit Lamp is a portable converging slit lamp with a camera attachment, designed for clinical settings that require both portable anterior segment examination and image or video capture. The product brochure shows the KJ5S3 fitted with a camera device attached to the slit lamp body, with two clinical capture images shown — consistent with an instrument designed for documenting anterior segment findings in portable clinical settings. The converging microscope provides 1X objective magnification with 10X and 16X eyepiece magnification steps, with all optical lenses treated for moisture and mildew resistance. Medigear.uk supplies the KJ5S3 Portable Slit Lamp and can advise on specification and procurement.

The light source is a white LED. The instrument is powered by a rechargeable 7.2V 750Ah Li battery. Dioptre compensation is ±7D. Pupil distance is 48–70mm. Working distance is 80mm. Slit width is continuously adjustable from 0 to 10mm. Slit angle is horizontal ±30°. The light spot specifications include both a set of selectable filter spot sizes — 1mm, 3mm, 5mm, and 10mm — and a base light spot diameter of 10mm, giving the examiner defined spot sizes for different anterior segment examination and imaging tasks.

Four filters are provided: heat-absorption, grey, red-free, and cobalt blue — the standard clinical filter set covering anterior segment examination, vascular assessment, and fluorescein staining. The camera attachment visible in the product photographs enables clinical image capture directly from the slit lamp during portable examination, supporting documentation in domiciliary, outreach, veterinary, and paediatric examination settings. Working time on the rechargeable battery is comparable to that of other models in the KJ5S portable range. Medigear.uk can confirm full specification, working time, and supply terms on request.

Ophthalmology outreach services, community eye care teams, and clinical settings requiring portable slit lamp examination combined with image capture capability represent the primary procurement context for the KJ5S3 Portable Slit Lamp. The camera attachment enables clinical photography of anterior segment findings during portable examinations. This capability combines the portability of a battery-powered slit lamp with the documentation benefits typically associated with clinic-based digital slit lamp platforms. Practitioners conducting domiciliary visits, paediatric eye examinations, and veterinary ophthalmology assessments can capture and record anterior segment images for referral, audit, and patient records directly from the KJ5S3 during the examination visit. Medigear.uk supplies the KJ5S3 and can advise on procurement.

NHS ophthalmology departments, hospital satellite clinics, and community optometry services requiring image documentation for remote specialist referral benefit from the KJ5S3's combination of portable converging slit lamp examination and camera capture. The four selectable spot sizes (1mm, 3mm, 5mm, 10mm) and four-filter set — heat-absorption, grey, red free, cobalt blue — cover the standard anterior segment examination requirements for both direct examination and image-documented examination workflows. The rechargeable Li battery provides independence from mains power during outreach or domiciliary sessions. Medigear.uk can advise on procuring KJ5S3 for NHS and community settings.

Veterinary ophthalmology practices, medical-legal and judicial examination services, and clinical training programmes requiring a portable slit lamp with image documentation capability for field or on-site use benefit from the KJ5S3's combined portable examination and camera attachment format. The KJ5S3 can be compared with the KJ5S1 (handheld, CE/FDA-certified) and the KJ5S2 (paediatric/veterinary/domiciliary focus) in the Medigear.uk portable slit lamp range. Contact Medigear.uk for specifications and pricing.

Camera Attachment for Clinical Image Capture During Portable Examination

The camera attachment is the defining feature of the KJ5S3 — enabling anterior segment image documentation during portable or field examination without a separate camera system. The brochure photographs confirm that the camera is mounted on the slit lamp body and that clinical anterior segment images are captured through the system.

Combines Portable Examination with Documentation Capability

The KJ5S3 addresses the gap between portable slit lamp examination (no documentation) and clinic-based digital slit lamp examination (not portable) — providing battery-powered portable examination with image capture in a single instrument.

Four Selectable Light Spot Sizes

1mm, 3mm, 5mm, and 10mm spot filter diameters allow the examiner to select the appropriate spot size for the examination task and for image capture at the selected magnification step.

Rechargeable Battery for Mains-Independent Use

The 7.2V 750Ah Li rechargeable battery supports use in domiciliary, outreach, veterinary field, and on-site examination settings without access to mains power.

Four-Filter Set for Full Anterior Segment Coverage

Heat-absorption, grey, red free, and cobalt blue — the standard clinical slit lamp filter set for examination and fluorescein staining, supporting documented fluorescein assessment in portable settings.

10X and 16X Converging Microscope

Two-step converging microscope magnification covers routine survey at 10X and detailed anterior segment assessment at 16X for examination and image documentation.

0–10mm Continuously Adjustable Slit

Full continuous slit range for all standard anterior segment illumination modes during both examination and image capture.

Comparable to KJ5S1 and KJ5S2 in Portable Range

Shares the same core optics and battery platform as the KJ5S1 (hand-held) and KJ5S2 (domiciliary/veterinary), with camera attachment as the KJ5S3's distinguishing feature. All three are available from Medigear.uk.

Camera Attachment

Mounted on the slit lamp body. Enables anterior segment imaging during portable examinations.

Microscope: Converging, 1X Objective, 10X and 16X

Two-step converging microscope. Moisture-proof, anti-reflection optical lenses.

Light Spot Filter: 1mm, 3mm, 5mm, 10mm

Four selectable spot diameters. Base spot diameter 10mm.

Filters: Heat-Absorption, Grey, Red Free, Cobalt Blue

Standard four-filter set for anterior segment, vascular, and fluorescein examination.

Slit Width: 0–10mm Continuous / Slit Angle: ±30°

Continuous slit width. Standard horizontal slit angle.

Battery: 7.2V 750Ah Li, Rechargeable

Mains-independent portable operation.

Light Source: White LED

Stable white LED for examination and image capture.

Diopter: ±7D / PD: 48–70mm

Standard dioptre and pupil distance adjustment.

UK Supply via Medigear.uk

Available through Medigear.uk. Compare with KJ5S1 and KJ5S2 for portable slit lamp procurement.

The KJ5S3 Portable Slit Lamp is a portable converging slit lamp with camera attachment suited to ophthalmology outreach, NHS domiciliary eye care, community eye examination, paediatric ophthalmology, veterinary use, and on-site examination settings requiring portable anterior segment examination combined with image capture for clinical documentation and referral — featuring 10X and 16X magnification, white LED illumination, rechargeable 7.2V Li battery, ±7D dioptre compensation, 48–70mm pupil distance, 80mm working distance, 0–10mm continuously adjustable slit width, four selectable spot sizes (1mm, 3mm, 5mm, 10mm), heat-absorption, grey, red-free and cobalt blue filters, and camera attachment. Contact Medigear.uk for specifications, pricing, or expert procurement assistance.

FAQ

Frequently Asked Questions

Everything buyers need to know about sourcing medical equipment through MediGear.

The KJ5S3 features a camera attachment mounted on the slit lamp body — visible in the product photographs — enabling clinical image capture during slit lamp examination. The brochure also includes two clinical photographs captured with the system, which appear to be anterior segment images. This distinguishes the KJ5S3 from the KJ5S1 and KJ5S2, which are standard portable slit lamps without camera attachment. Contact Medigear.uk for full details on the camera attachment and compatibility with recording devices.

The KJ5S3 provides two eyepiece magnification steps: 10X and 16X, with 1X objective magnification on a converging microscope. The 10X step supports efficient anterior segment survey, and the 16X step provides a more detailed assessment of the cornea, lens, and anterior chamber, as well as higher-quality image capture at maximum magnification.

The brochure lists two light spot entries: "Diameter of Light Spot Filter: 1mm, 3mm, 5mm, 10mm" and "Diameter of Light Spot: 10mm." This reflects that the instrument has four selectable light spot filter diameters (1mm, 3mm, 5mm, 10mm) and a base beam diameter of 10mm. The selectable filter sizes allow the examiner to choose the most appropriate spot for the examination task — from the 1mm pinpoint for fine lesion assessment to the 10mm spot for diffuse illumination.

Four filters are provided: heat-absorption (removes infrared radiation), grey (reduces illumination intensity), red-free (green filter for vascular contrast), and cobalt blue (used with fluorescein for corneal staining). This is the standard four-filter clinical set for anterior segment examination.

All three models share the same specifications for the converging microscope, LED, battery, magnification, dioptre, pupil distance, and working distance. The KJ5S3 is distinguished by its camera attachment for clinical image capture. The KJ5S1 is a hand-held one-hand operational instrument with CE, FDA, ISO 13485, and ISO9001 certification. The KJ5S2 is a standard portable format specified for use in children, animal, domiciliary, and judicial examination contexts. Contact Medigear.uk to compare all three models for your clinical and procurement requirements.

Yes — the KJ5S3's rechargeable battery, portable design, and camera attachment make it suitable for domiciliary examination, community outreach, and satellite clinic use where both portable anterior segment examination and image documentation are required. The camera attachment supports capturing findings for referral and patient records during the visit itself, without the need to transcribe or recall them for documentation separately.

The camera attachment supports documentation of anterior segment findings during portable examination — potentially including corneal assessment, anterior chamber examination, lens and vitreous assessment, and fluorescein staining results. The two clinical capture images shown in the brochure demonstrate the image quality achievable with the system. Contact Medigear.uk to confirm the specific camera attachment specification and image capture format.

The portable design, battery-powered operation, and camera attachment make the KJ5S3 potentially suitable for veterinary ophthalmology examination in clinical and field settings. For veterinary-specific procurement, the KJ5S2 is explicitly manufacturer-specified for animal and pet examination. Contact Medigear.uk to discuss which model is most appropriate for your veterinary ophthalmology requirements.

Medigear.uk is the UK supplier for the KJ5S3 Portable Slit Lamp. Contact Medigear.uk for pricing, full specification of the camera attachment, and procurement documentation.
