Saikang Q2w

The SK-C1 is the workhorse paediatric ward bed for routine inpatient stays from approximately age 4 to age 16 — the age range where a cot-bed is no longer appropriate but an adult ward bed is the wrong dimensional profile. Typical inpatient presentations served include post-operative recovery from elective paediatric surgery (tonsillectomy, adenoidectomy, hernia repair, orthopaedic procedures), short-stay medical admissions for asthma exacerbation and infectious presentations, observation following minor head injury, and step-down placements from paediatric HDU back to general ward. The narrower platform suits the body geometry of paediatric patients while leaving room for a parent to sit close at the bedside.

In paediatric day-surgery units, the SK-C1 supports the full day-case workflow — pre-operative observation, recovery from general anaesthetic, parent-supervised mobilisation, and discharge preparation. The two-crank manual articulation allows nursing staff to elevate the backrest for post-anaesthetic respiratory positioning, then lower it for resting periods, without the noise or complexity of electric controls in an environment where toddlers may attempt to operate them. The 0–35° knee-rest reduces shear during the post-anaesthetic recovery hour and supports comfortable seated posture for the meal and fluids stage of the discharge pathway.

For paediatric infectious-disease wards and respiratory paediatrics, the detachable PP platform is the key clinical feature — it allows full terminal-clean cycles between patients with rotavirus, norovirus, RSV, or other transmissible presentations without the prolonged turnaround that fixed-platform beds require. The six-fold aluminium side rails wipe clean with standard chlorine-based agents, and the four IV pole sockets support multi-line infusion setups for fluid management and antibiotic regimens. The bed is not specified for PICU, paediatric HDU continuous monitoring, or specialist oncology placements — for these settings, Saikang's electric paediatric range is the recommended Medigear.uk alternative.

Purpose-built paediatric dimensions rather than scaled-down adult bed

The 880 mm external width and 1940 × 780 mm platform are dimensioned specifically for paediatric inpatient use, not derived by trimming an adult ward bed. This matters for ward bay geometry — paediatric wards typically run higher bed-to-patient ratios with parent-stay seating beside each bed, and an over-wide bed crowds the family space. The proportions also suit the body geometry of children from approximately age 4 to age 16, supporting natural sleeping posture without the lateral void that an adult bed leaves around a smaller patient.

Six-fold aluminium side rails meeting paediatric entrapment standards

The side rails are designed to IEC 60601-2-52 paediatric entrapment clearances — the seven entrapment zones identified in the standard's paediatric annex are dimensioned out at the design stage rather than relying on add-on padding. Rail height above the mattress meets the elevated thresholds required for children under 12 years, and the six-fold mechanism allows partial lowering for parent-supervised access without full collapse. This is a measurable safety advantage over generic side rails marketed as "suitable for paediatric use" without specific standards evidence.

Detachable PP platform supports terminal-clean infection control

The PP mattress platform lifts out as a single panel, allowing routine and terminal-clean cycles to reach the underside and frame directly. In paediatric infectious-disease wards — where rotavirus, norovirus, RSV, and chickenpox presentations require routine bed-strip decontamination — this turnaround speed is clinically and operationally significant. Fixed-platform beds typically need extended off-line cleaning periods for transmissible presentations; the SK-C1's detachable design returns the bay to service substantially faster.

Manual two-crank operation suits paediatric ward workflow

Two retractable hand cranks at the foot end control backrest and knee-rest, giving nursing staff direct mechanical control without involving the patient or parent. Saikang publishes 100,000-cycle durability before maintenance, which is multi-year reliability under realistic ward use. The absence of mains electricity eliminates the safety overhead of toddler-accessible electric controls and removes a maintenance category — actuator replacement is the most common failure mode on electric paediatric beds, and the SK-C1 sidesteps it entirely.

Central-locking castors operable from head end

Four 5-inch double-side castors with central locking allow the bed to be immobilised from the bed end without leaving the head-of-bed position during emergencies. This matters in paediatric resuscitation scenarios where the nurse at the head end is maintaining airway and cannot reach individual castor brakes. The castors are sized for paediatric ward floor finishes (vinyl and sealed laminate) and turn smoothly even when the bed is loaded with platform, mattress, and patient.

Lower capital cost per bay than electric paediatric beds

The SK-C1 is positioned in Saikang's value-engineered manual range, with capital cost typically 40–55 percent of equivalent electric paediatric models. For paediatric ward placements where electric profiling is not clinically indicated — routine inpatient stays, day-surgery recovery, short-stay medical admissions — the manual specification delivers the right clinical function at the right procurement price. Trust paediatric divisions can equip more bays for the same capital envelope, which often matters more than per-bed feature parity.

Full UK regulatory pack under Medigear.uk importer registration

Each SK-C1 ships with CE marking under EU MDR, ISO 13485 manufacturer certification, IEC 60601-2-52 test reports including the paediatric annex, and a UK importer compliance certificate. Medigear.uk holds the MHRA importer registration and routes any field-safety notices, recalls, and incident reports. The pack is sufficient evidence for NHS Supply Chain framework compliance, CQC inspection, and trust-level paediatric procurement processes.

Stocked UK spares and fixed-price service network

Hand cranks, side-rail latches, castors, IV poles, and the PP platform panel are held in UK stock for next-working-day dispatch under warranty, removing the multi-week wait that imported-bed placements typically face on a part failure. Out-of-warranty service runs through Medigear.uk's fixed-price engineer network covering England, Wales, and Scotland, with transparent parts and labour pricing suitable for paediatric division budget planning.

Manual two-crank articulation system

Two retractable hand cranks at the foot end control backrest (0–75° ± 10°) and knee-rest (0–35° ± 10°) independently. The cranks fold into the foot board when not in use to clear the ward access aisle and resist accidental engagement by toddlers and visitors.

0–75° ± 10° backrest adjustment

Backrest elevates from flat to a maximum of 75° (with ±10° tolerance), supporting respiratory positioning, post-anaesthetic recovery, meals, reading, parent interaction, and bedside teaching activity. The 75° upper limit is calibrated for paediatric soft-tissue protection during prolonged seated periods.

0–35° ± 10° knee-rest adjustment

The knee section elevates 0–35° independently of the backrest, reducing sacral shear during prolonged bed rest and creating a stable seated profile that resists patient slide-down. Knee-rest is particularly useful in post-operative paediatric orthopaedic placements.

2185 × 880 mm external dimensions

External footprint is paediatric-scaled at 2185 mm length and 880 mm width, fitting standard UK children's ward bay layouts with parent-stay seating preserved alongside. The reduced width compared to adult ward beds creates space for the family-presence model that characterises modern paediatric inpatient care.

1940 × 780 mm mattress platform

The platform accepts paediatric pressure-redistribution mattresses sized for children from approximately age 4 to age 16. The 1940 mm length supports older children up to approximately 1850 mm in height, and the 780 mm width supports comfortable lateral movement without excessive lateral void around smaller patients.

540 mm fixed deck height

Deck height is fixed at 540 mm, calibrated for paediatric nursing assessment posture and parent-supervised mobilisation. Fixed height eliminates the maintenance category of height-adjustment mechanisms and is appropriate for routine paediatric ward use where variable-height profiling is not clinically required.

Six-fold aluminium-alloy side rails

Side rails fold in six sections, with stainless-steel poles and plastic handle. Entrapment-gap geometry meets IEC 60601-2-52 paediatric annex clearances, and rail height above the mattress exceeds the elevated thresholds required for children under 12 years.

5-inch double-side castors with central locking

Four 5-inch castors with double-side construction and a central locking system operable from the bed end. Central locking allows nursing staff to immobilise the bed during emergencies without leaving the head-of-bed position.

Detachable PP bed surface with mattress holder

The PP mattress platform lifts out as a single panel for terminal-clean cycles, with a moulded mattress holder at the head end that prevents lateral sliding during articulation and active patient movement.

Bed end with medical record card holder

The foot board carries a moulded paper record card holder, accommodating the paediatric observation chart formats that remain in widespread UK use alongside electronic systems. The holder is angled for reading without removal.

Four IV pole sockets at corners

Each corner of the platform carries a stainless-steel IV pole socket, allowing multi-line infusion setups for paediatric fluid management, antibiotic regimens, and PCA placements.

Telescopic stainless-steel IV pole

One telescopic IV pole is supplied as standard, with four plastic hooks rated to 15 kg total load. The pole inserts into any of the four corner sockets and adjusts in height for paediatric drip-chamber visibility.

Two ABS drainage hooks

Two drainage hooks attach to the side rails for paediatric urinary catheter bags, wound drainage bottles, and chest drain bottles where applicable. The ABS construction wipes clean with chlorine-based agents.

Moulded shoes holder

A shoes holder under the foot end keeps the patient's outdoor footwear off the ward floor, supporting infection control and preventing trip hazards in the bay. This is a small detail that recurs in paediatric ward operational reviews.

Epoxy-coated steel frame on Baosteel raw material

Frame steel is sourced from Baosteel (Fortune Global 500 supplier) and finished with an 11-process automotive-grade epoxy coating tested to 50 kg impact resistance. The coating tolerates routine chlorhexidine, isopropanol, and chlorine wipe-down without paint failure.

CE marking under EU MDR

Full CE compliance under the EU Medical Device Regulation, with Declaration of Conformity and technical file extracts supplied at delivery. Required for any UK NHS or insurer-funded paediatric placement.

ISO 13485 manufacturer certification

Saikang manufactures under ISO 13485 quality management, with audit-trail evidence of design control, supplier control, and post-market surveillance across the production lifecycle. Certificate is supplied with each unit.

IEC 60601-2-52 paediatric annex compliance

Tested to the international safety standard for medical beds including the paediatric annex covering entrapment, side-rail dimensions, articulation safety, and electrical safety. Test report is part of the standard delivery pack.

The Saikang Q2w (SK-C1) supplied through Medigear.uk gives UK paediatric divisions a properly dimensioned, properly certified manual ward bed at a procurement price that supports equipping the whole bay rather than half of it. The platform is paediatric-scaled rather than scaled down from adult, the side rails meet IEC 60601-2-52 paediatric entrapment clearances rather than relying on add-on padding, and the detachable PP surface supports the terminal-clean turnaround that paediatric infectious-disease workflows require. With CE marking under EU MDR, ISO 13485 manufacturing, UK-stocked spares, and Medigear.uk's MHRA importer registration handling the regulatory routing, the SK-C1 is a defensible specification for NHS children's wards, paediatric day-surgery units, step-down placements from HDU, and private paediatric inpatient providers across the United Kingdom.
