Roundfin XH-4002 Paraffin Dispenser

Home
Shop
Lab, Pathology & Blood Bank
Roundfin XH-4002 Paraffin Dispenser

✓ Certified Professional Seller

Roundfin Lab, Pathology & Blood Bank

Roundfin XH-4002 Paraffin Dispenser

The Roundfin XH-4002 Paraffin Dispenser is a 10L wax paraffin dispenser for histopathology embedding laboratories, featuring fully automated computer control, intelligent digital temperature control, US-made temperature sensors, new-type fast-heating elements, auto-save memory for preset temperatures, LED heating status display, and a continuously adjustable 0–85°C temperature range. Available through Medigear.uk.

Sections

Embedding Centers

Categories

Lab, Pathology & Blood Bank

Condition

New

Origin

China

Seller Type

Certified Professional Seller

CE & ISO Certified

Global Shipping

Supplier: Medigear

The Roundfin XH-4002 Paraffin Dispenser is a 10-litre wax paraffin dispenser designed for histopathology and pathology embedding laboratories where molten paraffin wax must be dispensed into embedding moulds at controlled, consistent temperatures during the tissue embedding stage. The instrument utilises fully automated computer control with intelligent digital temperature management to maintain an accurate and consistent wax temperature across the full 10-litre capacity — removing the guesswork and manual monitoring associated with simpler paraffin bath designs. Medigear.uk supplies the XH-4002 and can advise on configuration and procurement.

The temperature sensors are made in the USA, providing precise and reliable temperature monitoring across the wax bath. New-type heating elements enable fast, energy-efficient, and reliable heating, minimising the warm-up time required to bring the full 10L wax volume to the set working temperature. The auto-save and memory functions automatically save the latest operating settings after device use, and the automatic restoration function reapplies the preset temperature at the next power-on cycle without manual re-entry — a time-saving feature for laboratories with consistent daily embedding protocols. The LED display shows the heating status during operation, confirming when the target temperature has been reached, and dispensing can begin. The combination of US-made sensors, new-type heating elements, and intelligent computer control positions the XH-4002 as an advanced wax paraffin dispenser within the Roundfin histopathology instrument range.

The temperature range is continuously adjustable within 0–85°C. Product size is W350×D410×H480mm. Voltage is AC 220V/50Hz or AC 120V/60Hz. Power is 1060W. Capacity is 10L. Net weight is 17kg. Working temperature is 5°C–40°C, with relative humidity below 80%. We can provide the full specification and supply terms on request.

NHS histopathology departments, hospital pathology laboratories, and diagnostic services that require a high-capacity, computer-controlled paraffin wax dispenser for the tissue embedding stage are the primary procurement context for the Roundfin XH-4002 Paraffin Dispenser. In the histopathology workflow, processed tissue is embedded in molten paraffin wax within metal or plastic embedding moulds. This stage requires a consistent wax temperature to ensure proper infiltration and block formation. The XH-4002's 10L capacity, US-made temperature sensors, and automatic temperature restoration support continuous high-volume daily embedding sessions. Medigear.uk supplies the XH-4002 and can provide NHS procurement documentation.

Hospital surgical pathology departments, cancer diagnostic centres, and specialist biopsy services benefit from the XH-4002's computer-automated control and intelligent digital temperature management, which maintains consistent wax dispensing temperature across the 10L capacity throughout the working session. The auto-save memory means the set embedding temperature is restored at the start of each session without requiring manual reset, and the LED status display confirms heating progress before dispensing begins. Medigear.uk can advise on XH-4002 configuration for high-volume surgical pathology settings.

Medical colleges, university histology departments, and teaching hospitals benefit from the XH-4002's straightforward automated temperature control and LED status display, which provide reliable wax-dispensing performance without the need for complex manual temperature management in teaching environments. The US-made sensors and fast heating elements support consistent session start-up. Medigear.uk can advise on the procurement of XH-4002 for medical education settings.

Research histology laboratories, food testing facilities, and private pathology services requiring a large-capacity paraffin wax dispenser will find the Roundfin XH-4002 available through Medigear.uk. The dual voltage AC 220V/120V specification supports international deployment. Medigear.uk can discuss the supply terms for XH-4002 upon request.

Full Computer Automated Control for Consistent Wax Temperature

The XH-4002's fully automated computer control system continuously monitors and adjusts the heating element output to maintain the set wax temperature across the entire 10L volume — providing more consistent temperature control than mechanical thermostat systems and eliminating the need for manual temperature monitoring or adjustment during embedding sessions.

US-Made Temperature Sensors for Precise Monitoring

The US-manufactured temperature sensors provide precise, reliable temperature readings throughout the wax bath, ensuring the computer control system has accurate data to work with. In paraffin dispensing, sensor accuracy directly affects the accuracy of dispensing temperature, which in turn influences tissue infiltration quality and block hardness. The US-origin sensor specification is a quality differentiator cited explicitly by the manufacturer.

New-Type Fast Heating Elements for Efficient Session Start

The new-type heating elements enable fast heat-up of the full 10L wax volume, reducing waiting time at session start. Energy-efficient heating reduces power consumption relative to heating capacity, and reliable heating-element construction supports consistent long-term performance throughout the instrument's working life.

Auto-Save Memory and Automatic Temperature Restoration

The auto-save and automatic restoration system saves the last-used temperature settings and restores them at the next power-on without manual entry. For laboratories with consistent daily embedding temperatures, this eliminates setup time at the start of each session and removes the risk of selecting an incorrect temperature before dispensing begins.

LED Heating Status Display

The LED display provides real-time visual confirmation of whether the XH-4002 has reached its set temperature and is ready for dispensing. This allows the operator to prepare other embedding materials while the wax heats, and to confirm readiness before beginning the embedding session without guesswork.

10L Large Capacity for Continuous Embedding Sessions

The 10-litre wax capacity supports extended daily embedding sessions in high-throughput histopathology laboratories without frequent refilling. This large capacity is particularly relevant in NHS surgical pathology departments and cancer diagnostic centres where large numbers of cassettes are embedded each day.

Continuously Adjustable 0–85°C for Diverse Wax Formulations

The continuously adjustable 0–85°C range allows the XH-4002 to be precisely set for different paraffin wax formulations with varying melting and working temperature requirements. Continuous adjustment (rather than stepped settings) enables fine-tuning to the specific wax being used.

Dual Voltage AC 220V/120V for International Deployment

AC 220V/50Hz and AC 120V/60Hz dual-voltage support enables deployment in European and North American electrical environments without a converter, facilitating international research procurement and cross-border laboratory network supply.

Full Computer Automated Control

Intelligent digital temperature management. Continuous automatic adjustment to maintain the set temperature.

US-Made Temperature Sensors

Precise and reliable wax temperature monitoring. US-origin sensor quality.

New-Type Heating Elements

Fast, energy-efficient, reliable heating for 10 L of wax.

Auto-Save Memory and Automatic Restoration

Preset temperature saved and restored at power-on. No manual re-entry required.

LED Heating Status Display

Visual confirmation of heating progress and dispensing readiness.

Capacity: 10L

Large volume for continuous high-volume embedding sessions without refilling.

Temperature Range: 0–85°C Continuously Adjustable

Fine-tune for diverse paraffin wax formulations—no stepped adjustment required.

Power: 1060W

High power for fast heating of 10L wax volume to working temperature.

Product Size: W350×D410×H480mm; 17kg

Bench-top embedding station footprint. Working environment 5°C–40°C.

Dual Voltage: AC 220V/50Hz, AC 120V/60Hz

International electrical compatibility without a converter.

1-Year Warranty

Supplied through Medigear.uk with warranty and technical support.

Medigear.uk — UK Supplier

Full Roundfin histopathology range available through Medigear.uk, including paraffin dispensers, trimmers, and processing instruments.

The Roundfin XH-4002 Paraffin Dispenser is a 10L wax paraffin dispenser suited to NHS histopathology departments, hospital surgical pathology laboratories, cancer diagnostic centres, medical colleges, and research facilities requiring a high-capacity, computer-automated paraffin wax dispensing instrument with US-made temperature sensors for precise and reliable monitoring, new-type energy-efficient fast heating elements, intelligent digital temperature control across a 0–85°C continuously adjustable range, auto-save memory and automatic temperature restoration at each power-on for consistent session start, LED heating status display confirming readiness for dispensing, 1060W power, and dual voltage AC 220V/120V international compatibility in a 10L 17kg design. Contact Medigear.uk for specifications, pricing, or expert procurement assistance.

FAQ

Frequently Asked Questions

Everything buyers need to know about sourcing medical equipment through MediGear.

A paraffin dispenser is a heated-wax bath instrument used in histopathology during the tissue-embedding stage. After tissue processing, processed tissue must be embedded in molten paraffin wax within metal or plastic embedding moulds to create the paraffin block from which sections are cut on the microtome. The paraffin dispenser holds a large volume (10L in the XH-4002) of molten wax at a controlled temperature, and the operator dispenses wax into each mould by opening a valve or tap — filling the mould, positioning the tissue, and allowing the wax to solidify into a block. Consistent wax temperature is critical for proper tissue infiltration and block formation.

Full computer-automated control means the XH-4002's temperature management is handled entirely by an onboard computer system rather than by a mechanical thermostat or manual adjustment. The computer continuously monitors the temperature sensor readings and automatically adjusts the heating element output to maintain the set temperature precisely across the 10L wax volume. This automated control eliminates manual temperature adjustment during the working session and provides more consistent temperature maintenance than mechanical thermostat systems.

The manufacturer explicitly cites the US origin of the XH-4002's temperature sensors as a quality and precision feature — US-manufactured sensors are described as precise and reliable. In a paraffin dispenser, sensor accuracy directly affects the dispensing temperature, which in turn influences tissue infiltration quality and block hardness. The use of US-made sensors is a technology positioning statement aligned with similar US-component claims in the Roundfin RD-86 tissue floating bath (US-made single-chip microprocessors).

The new-type heating elements cited by the manufacturer enable fast, energy-efficient, and reliable heating of the 10L wax volume. In paraffin dispensers, heating element type affects the speed and evenness of wax heating — conventional elements may require long warm-up times and can create temperature gradients across the wax volume. The new-type elements in the XH-4002 are designed to improve heating speed and efficiency, reducing the time required to bring the full 10L volume to working temperature.

The auto-save function automatically saves the most recent operation settings — including the preset temperature — each time the XH-4002 is used. The automatic restoration function reads these saved settings at the next power-on and restores the preset temperature without requiring manual re-entry. For histopathology embedding laboratories with consistent daily embedding temperatures, the XH-4002 automatically starts each session at the correct temperature, saving setup time and eliminating the risk of incorrect temperature entry.

The LED display shows the heating status of the XH-4002 during operation. This allows the operator to monitor whether the instrument has reached the set temperature and is ready for wax dispensing, or is still warming up. The LED status display is a practical indicator for embedding workflow management — the operator can begin preparing moulds and tissue. At the same time, the XH-4002 heats up and checks the LED status before beginning dispensing.

The XH-4002 has a 10-litre wax capacity. This large volume enables extended daily embedding sessions in high-throughput pathology laboratories without frequent wax refills. For smaller volume applications, the continuously adjustable 0–85°C temperature range accommodates different wax formulations and embedding protocols within the same instrument.

The XH-4002 is a paraffin dispenser used during the embedding stage — before sectioning. The TR-302 and XH-90 paraffin trimmers are used during the pre-sectioning stage — after embedding and before the microtome. In the histopathology workflow: tissue is embedded using the XH-4002 (wax dispensing) → the block is chilled and removed from the mould → excess wax is trimmed using the TR-302 or XH-90 (paraffin trimming) → the block is sectioned on the microtome. These three instruments cover three adjacent stages of the paraffin wax histopathology workflow.

The XH-4002 supports AC 220V/50Hz and AC 120V/60Hz, enabling deployment in European and North American electrical environments without a converter. Medigear.uk can confirm voltage compatibility on request.

Yes — Medigear.uk is the UK supplier for the Roundfin XH-4002 Paraffin Dispenser and the complete Roundfin histopathology instrument range. Contact Medigear.uk for pricing, specifications, procurement documentation, and supply terms.
