OrthoHeal FlexiOH Ulnar Gutter

It is consistent and it points one way, so it is worth knowing before standardising. A randomised trial by Statius Muller and colleagues compared a pressure bandage with immediate mobilisation against three weeks in an ulnar gutter cast for fractures angulated up to 70 degrees, and found no difference in range of motion, pain, satisfaction, return to work or need for physiotherapy. A multicentre randomised trial of 68 patients by van Aaken and colleagues found soft wrap with buddy taping non-inferior on function, pain, grip strength and mobility at four months, with return to work eleven days sooner. A systematic review published under the title stating that splint immobilisation is not necessary concluded that casting is not superior to soft wrap without reduction in most cases. A 2022 systematic review found level 1b evidence for soft wrap and buddy strapping with early active mobilisation at angulation under 70 degrees.

When the fracture is one the evidence does not cover. Rotational deformity — the digit scissoring across its neighbour when the hand closes — is a surgical indication rather than a casting one, but the cases between are where immobilisation earns its place: angulation beyond what your service accepts, fractures of the ring or little finger phalanges rather than the metacarpal neck, base and shaft fractures with less inherent stability, post-operative immobilisation after fixation, and patients who genuinely cannot be relied on to maintain buddy taping. Departments that cast by default for this injury should look at the evidence. Departments that cast by decision will still need a device.

Considerably. An ulnar gutter runs the little-finger side and holds the ring and little fingers, leaving the thumb, index and middle fingers outside it. That preserves pinch and most fine hand function, which is the majority of what a hand does. It also means the device is inherently side-specific, so left and right versions almost certainly exist. The sheet gives three size codes with no handedness designation. Confirm it and confirm the labelling, because three codes then become six stock lines and an order placed on size alone will arrive half wrong.

Not stated, and on a hand device this is the question that decides the outcome. The collateral ligaments at the knuckle joints are taut in flexion and slack in extension, so a hand immobilised with the knuckles straight allows those ligaments to shorten, and the patient cannot close the hand afterwards. Established practice is knuckles flexed between 70 and 90 degrees with the joints beyond fully straight and the wrist slightly extended. Ask the seller for those figures in degrees, and ask whether the joints beyond the knuckle are held or left free to move.

Because pressure injury is a recognised complication of hand immobilisation, and the ulnar border is where it concentrates. Comparative work on immobilising fifth metacarpal fractures has recorded lower pressure wound rates where the skin remained accessible. An open lattice allows the skin over the ulnar border, between the held digits and at the wrist to be inspected directly at review without removing anything, and it lets the patient wash properly through the immobilisation period.

Younger adults, and disproportionately young men, since the injury is commonly sustained striking something. That population matters commercially as well as clinically: they are working, often manually, they are the least tolerant of three weeks in a rigid device, and they are the most likely to remove it, soak it or return with it damaged. A device the patient can wash, that vents, and that can be opened and refitted at review is one more likely to stay on and stay intact for the period it is needed.

The retaining strap releases the digits, and the shell is designed to be removable and refitted. Confirm the exact closure and removal method with the seller before the first fitting, and whether it opens along its full length. If compartment syndrome is suspected the immobilisation must come off completely and immediately, including any padding, with the limb elevated to heart level. That method should be documented locally and covered in familiarisation rather than worked out under pressure.

Hands swell markedly after injury and resolve slowly, so circumference at fitting is not circumference at review. Too tight risks neurovascular compromise and pressure injury across the superficial ulnar nerve territory. Too loose lets the digits shift inside the gutter, which undoes the positioning the device exists to provide. Ask what adjustment range the retaining strap offers once the shell has cured, and whether a size change mid-treatment means a new device and a new cost.

Documented neurovascular assessment. British Orthopaedic Association Standards for Trauma require clear documentation of peripheral nerve and vascular status after injury, manipulation, cast fitting and surgery, and fitting this device is a cast fitting for that purpose. UK audit work shows the standard is frequently not met, with one hospital audit finding detailed nerve function documented in only a tenth of cases and arterial status missing from more than half. The ulnar nerve is superficial at the wrist and elbow and specific in its distribution, so a generic entry recording that everything is intact says very little.

The open lattice leaves a substantial proportion of skin exposed and the material is described as washable, so washing and showering are part of intended use. Given who wears these and for how long, that is the single feature most likely to determine whether the device is still on the hand at review. Obtain the manufacturer's guidance on drying and full immersion, establish whether a liner is used underneath, and issue written patient instructions covering the skin between the held digits.

Request this in writing. A washable, strapped device invites the assumption it can be reprocessed between patients, and that assumption should never be made without the manufacturer confirming it. On a high-volume emergency department indication the answer carries real commercial weight. If single patient use, it is a per-episode consumable with a disposal route. If reprocessable, expect a defined decontamination method, a cycle limit, and the strap to inspect as a separate component.

OrthoHeal is an Indian manufacturer, and the FlexiOH range is distributed through European medical retail channels, which implies CE marking for the variants sold there. No CE marking or UKCA position is evidenced on the supplied sheet for the Ulnar Gutter, and this page makes no such claim on its behalf. Request the declaration of conformity, certificate scope, instructions for use and current UKCA position from the seller at quotation, and treat all four as conditions of order. Device classification under the UK Medical Devices Regulations 2002 is confirmed against the declaration at order.
