Aquamaxx CC200

Supervised aquatic exercise and rehabilitation settings gain the most from the CC200's defining characteristic: its resistance is numerically defined rather than approximate. A practitioner can set the flow at the lower end of the 1.8 to 2.3 metres per second range and record the exact conditions under which the session was performed, then reproduce them precisely at the next appointment. Working in water reduces joint loading through buoyancy, while the current provides consistent, measurable resistance. The CC200 is supplied as aquatic exercise equipment, and programme design remains the responsibility of the qualified practitioner directing the session, with Medigear.uk providing manufacturer documentation for a facility's own equipment assessment.

Fitness and leisure facilities use the CC200 to add swim capability where a full-length lane pool is not viable. One station converts an existing exercise or plunge pool into a continuous swimming resource, expanding programme options without capital construction. Bluetooth control allows an instructor to adjust intensity from the poolside during a supervised class, and the stainless steel handrail supports safe entry and exit between sets. Medigear.uk supplies facility operators on account terms with documentation suited to commercial installation.

Private and residential pools benefit because domestic pools are rarely long enough to swim in properly. A pool meeting the 1.1 to 1.8 metre depth specification becomes capable of unlimited continuous swimming, changing an occasional amenity into usable daily exercise capacity. The drive station's roller design means the installation can be adjusted rather than fixed permanently at first attempt. Medigear.uk supports individual buyers from pool assessment through to installation documentation.

Swim coaching environments use fixed-point swimming for stroke correction, since a swimmer holding position stays under continuous observation from the poolside. Higher flow settings support pacing and aerobic work,k while lower settings suit controlled technique drill.nd Medigear.uk advises on configuration for coaching use.

Numerically Defined Resistance Between 1.8 and 2.3 Metres per Second

The CC200's flow range is published and adjustable, which means the training or exercise condition can be recorded rather than estimated. Repeatability of this kind matters wherever progress must be demonstrated rather than assumed. A user returns to a known setting and works under identical conditions each session. That is a materially different proposition from unstructured pool exercise.

Laminar Flow Rather Than Turbulent Jet

Discharge through the 500 × 420 mm outlet is laminar, presenting a smooth column of moving water across the swimmer's body. Even resistance produces a more natural stroke than broken turbulence, which tends to destabilise body position. This directly affects how long a swimmer can sustain a set. It also makes the machine better suited for technical work.

Electrical Plant Separated From the Water

The independent hydraulic drive places the power source at a station away from the pool edge, linked to the pool by two insulated, corrosion-resistant lines. This reduces electrical exposure in the wet zone and puts serviceable components where a technician can work on them dry. For facility operators, this simplifies both risk assessment and access for maintenance. It is the single most significant design decision in the model.

Compact Plant Footprint Under Half a Square Metre

The drive station measures 840 × 490 × 900 mm and occupies less than 0.5 m² of floor. Plant space is usually the constraint that prevents equipment upgrades in existing buildings, and this footprint helps keep that constraint manageable. The roller design allows repositioning without lifting 115 kg of equipment. Siting can therefore be revised after commissioning if required.

In-Water Control Without Leaving the Pool

The wireless Bluetooth remote lets the swimmer or supervising practitioner change flow mid-session without reaching a fixed panel. Sessions can move between working and recovery intensity without breaking rhythm. For supervised work, this keeps the practitioner beside the user rather than at a control point. Medigear.uk supplies pairing documentation with each unit.

Complete Operating Package on Delivery

Supply includes the machine, drive station, hydraulic oil charge, both 4-metre lines, remote controller,r and stainless steel handrail. There is no separate sourcing exercise before the equipment can be commissioned. Medigear.uk issues a written inclusion list with the quotation, so nothing is assumed. This matters most on installations working to a fixed opening date.

Verified Manufacturer Provenance and Documentation

The CC200 comes from a manufacturer that has been producing leisure, sports, and rehabilitation equipment since 2000. Where specifications or certifications are not published for this model, Medigear.uk obtains them in writing rather than estimating. Buyers therefore commit against confirmed figures. This is applied to every order, regardless of value.

Distributor Volume Supply and Individual Buyer Support

The same specification rigour applies whether the order is a single domestic installation or a distributor consignment. Volume buyers receive factory dialogue on configuration and minimum quantities handled by Medigear.uk, while private buyers receive pool depth assessment and installation documentation. Freight planning accounts for the two-part shipment in both cases. Written lead times are issued either way.

Current Speed: 1.8 to 2.3 Metres per Second

Countercurrent output is adjustable across a published range of 1.8 to 2.3 metres per second. This spans controlled movement at the lower setting through to sustained conditioning work at the upper setting. The defined range is what allows sessions to be recorded and reproduced.

Effluent Outlet: 500 × 420 mm Rectangular Laminar Flow

Water is discharged through a rectangular outlet measuring 500 × 420 mm in laminar flow. The rectangular geometry distributes flow across the swimmer's width rather than concentrating it. Laminar discharge provides uniform resistance rather than the destabilising turbulence of a point jet.

Operating Water Depth: 1.1 to 1.8 Metres

The CC200 is specified for pool water depth between 1.1 and 1.8 metres. This window governs pool suitability and must be measured at the intended installation point. Medigear.uk verifies depth against this figure before confirming any order.

Independent Hydraulic Drive System

Power is delivered hydraulically from a station independent of the poolside unit rather than by an integrated electric pump. This separates electrical plant from the wet environment. It also concentrates serviceable components in a single accessible location.

Hydraulic Drive Station: 840 × 490 × 900 mm

The drive station measures 840 × 490 × 900 mm and occupies under 0.5 m² of floor area. Its compact footprint suits plant rooms and service spaces where floor area is limited. The 4 metre hydraulic line length constrains positioning.

Hydraulic Oil Capacity: 35 Litres

The system holds 35 litres of hydraulic oil, which forms the basis of the maintenance schedule. Oil level and condition are the primary routine checks on the drive system. The manufacturer sets replacement intervals according to usage.

Wireless Bluetooth Remote Control

One wireless Bluetooth remote controller is supplied with the machine for flow adjustment during use. Control is possible from within the water or from the poolside without a fixed panel. This suits both independent training and supervised sessions.

Stainless Steel Handrail

A single stainless steel handrail is included as standard for entry, exit and steadying during technique work. Stainless construction is specified because the component remains in permanent contact with treated pool water. It forms part of the standard supply rather than an accessory.

Machine Weight: 35 kg Net, 45 kg Gross

The swim unit weighs 35 kg net and 45 kg gross. This is manageable for poolside handling and positioning during installation. Gross weight applies to crated shipment.

Drive Station Weight: 115 kg Net, 145 kg Gross

The hydraulic drive station weighs 115 kg net and 145 kg gross, substantially heavier than the swim unit. Delivery access and final siting must account for this before the consignment arrives. Medigear.uk factors the two-part weight distribution into freight planning.

Anti-Corrosion Insulated Hydraulic Lines: 4 m × 2

Two insulated anti-corrosion hydraulic lines, each 4 metres long, connect the drive station to the poolside machine. Insulation and corrosion resistance are specified because the lines run through a wet, chemically treated environment. Their length determines the maximum separation between the station and the pool.

Roller-Mounted Drive Station

The drive station features a roller design that allows it to be moved without lifting. Repositioning a 115 kg unit by hand would otherwise require equipment. This makes siting adjustable after commissioning rather than fixed at first installation.

Adjustable Countercurrent Performance

Countercurrent output is adjustable rather than running at a single fixed rate, which allows a single machine to serve users with very different capability levels. Adjustment is made through the remote controller during use. This breadth suits shared and multi-user installations.

Two-Part Wet and Dry Architecture

The machine separates into a poolside wet component and a dry drive station, each with distinct siting and handling requirements. This architecture enables electrical separation and a compact plant footprint. It also means installation planning covers two positions rather than one.

Documentation Pack Supplied at Order

Every CC200 is accompanied by the manufacturer's technical documentation, installation guidance, the maintenance schedule, and applicable certification records. Medigear.uk assembles this pack at order rather than leaving buyers to source it afterwards. Where a parameter is unpublished, its confirmed value is supplied in writing.

The CC200 Intelligent Auxiliary Swim Machine answers the problem that most pools are too short to swim in properly, and it does so with figures a buyer can actually verify. Adjustable laminar flow from 1.8 to 2.3 metres per second, a 500 × 420 mm outlet and a defined 1.1 to 1.8 metre depth window make it suitable for private pools, fitness and leisure facilities, supervised aquatic programmes and swim coaching alike. An independent hydraulic drive keeps electrical plant clear of the water, while Bluetooth control and a stainless steel handrail support both independent and supervised use. Certification records are verified against this specific model before supply. Contact Medigear.uk for specifications, procurement assistance, or expert consultation.
