Siemens MAGNETOM Avanto 1.5T (2017)

Whole-body oncological staging is the setting the coil architecture was built for, since 205 cm can be acquired continuously without stopping to reposition the patient or change coils.

Peripheral angiography benefits from the same continuous coverage combined with parallel acquisition, so a run-off study completes without separate station set-ups.

Neurological imaging is supported by head and neck matrix coils with AutoAlign positioning slices to a reference anatomy for reproducible follow-up.

Musculoskeletal imaging draws on the dedicated knee, shoulder, wrist, foot and ankle arrays alongside flex and loop coils for smaller or awkward regions.

Body and abdominal imaging uses body and spine matrix elements combined into a single matrix, with respiratory gating available for motion-sensitive sequences.

Cardiac imaging is supported by ECG and peripheral gating with the steady-state and echo-planar sequence families.

Patients who find head-first entry difficult are accommodated by feet-first positioning, which is supported for nearly all procedures on this platform.

Coverage That Does Not Stop at the Coil

Elements integrated along the table and within applied coils are combined into one matrix, so imaging extends to 205 cm without repositioning.

Elements From Separate Coils Used Together

Physically separate coils are combined electronically under system selection, so a region spanning two coils is imaged as one.

76 Elements Through 32 Channels

Up to 76 matrix coil elements are addressed through up to 32 independent RF receiver channels in a single imaging matrix.

Acceleration Without Losing Coverage

Because many elements view the anatomy simultaneously, parallel acquisition runs to high factors while body coverage is maintained.

Reproducible Slice Geometry

AutoAlign positions slices to a reference anatomy, so a follow-up study matches the geometry of the one before it.

Results Produced During Acquisition

syngo Inline processing generates results as images are acquired, so post-processing does not sit as a separate stage afterwards.

Protocols Recalled From Prior Images

Phoenix and PhoenixZIP store and recall protocols from previously acquired images, so a study can be repeated exactly.

Feet-First Positioning as Standard Practice

Nearly all procedures can be performed feet first, which widens the range of patients a department can accommodate.

Wide Resolution Range

Field of view from 5 mm to 500 mm with matrices to 1024 by 1024 supports both small field-of-view detail and whole-body coverage.

A Table Taking 250 kg

Patient support to 250 kg widens the range of patients a department can accept.

Coil Set and Configuration Documented

The Tim generation, channel count and coil set are provided by the seller at quotation, so the practical clinical range is established in writing.

1.5 Tesla Whole-Body Superconducting MRI System

A compact short-bore magnet with gradient system, RF chain, patient table and operator console.

Year of Manufacture: 2017

Bearing on Tim generation, software release, coil compatibility and support arrangements.

Total Imaging Matrix

Coil elements integrated along the table and within applied coils, combined electronically into one imaging matrix.

Up to 76 Matrix Coil Elements

Addressed as a single matrix across the imaged region.

Up to 32 Independent RF Receiver Channels

Supplied in 8, 18 and 32 channel configurations, with the count on this system confirmed at quotation.

Whole-Body Coverage: Up to 205 cm

Acquired without coil or patient repositioning.

iPAT Parallel Acquisition

Acceleration to high factors with body coverage maintained.

Patient Bore: 60 cm

A compact short-bore design with a flared opening.

Field of View: 5 mm to 500 mm

Across small field-of-view and whole-body work.

Measurement Matrix: 64 × 64 to 1024 × 1024

With a 1024 by 1024 full screen display matrix.

Minimum Slice Thickness

0.1 mm in two-dimensional acquisition and 0.05 mm for a three-dimensional partition.

Feet-First Positioning

Supported for nearly all procedures on this platform.

Patient Table Capacity: 250 kg

For positioning across the full coverage range.

syngo Inline Technology

Results produced during acquisition without a separate post-processing stage.

syngo AutoAlign

Automatic slice positioning against a reference anatomy for reproducible geometry.

syngo Phoenix and PhoenixZIP

Protocols stored in and recalled from previously acquired images.

syngo Expert-i

Remote participation in a scan from outside the scanner room.

Day Optimizing Throughput

Protocol guidance applied across the examination workflow.

Sequence Families

Gradient echo, inversion recovery, STIR, FLAIR, true steady-state free precession, fast and single-shot spin echo, magnetisation transfer, echo-planar, 3D DESS, CISS and PSIF.

Spectroscopy

Single-voxel and chemical shift imaging, available where that option is present.

Gating and Synchronisation

ECG, peripheral and respiratory gating with external synchronisation inputs.

Acoustic Noise Reduction

Available according to the software and options fitted on this system.

Matrix and Dedicated Coil Range

Head, neck, spine, body, breast, shoulder, knee, wrist, foot and ankle arrays with flex and loop coils and an endorectal interface, with those supplied listed at quotation.

Magnet Condition and Helium History

Cryogen level and fill history provided by the seller at quotation.

CE Marking and Declaration of Conformity

Issued by the manufacturer and requested from the seller at quotation.

Decontamination Certificate and Warranty Terms

Provided by the seller at quotation, in line with normal practice for used imaging equipment.

Siting and Installation

Magnet siting, floor loading, RF shielding, quench pipe routing, chiller capacity and power supply assessed before installation, which Medigear.uk can arrange.

This Siemens MAGNETOM Avanto 1.5T was built in 2017, and the case for it rests on where an examination has to stop. Coil coverage has traditionally set that boundary, with anything beyond the applied coil meaning a halt, a repositioned patient, a different coil and a registration problem between what came before and after. Total imaging matrix integrates elements along the table and within the applied coils and combines them electronically into a single matrix, addressing up to 76 elements through up to 32 independent RF receiver channels and extending coverage to 205 cm without moving the patient, so a whole-body study runs as one continuous acquisition. Parallel acquisition builds on the same architecture, running to high factors while coverage is held. Around it sit a 60 cm short bore with feet-first positioning for nearly all procedures, a 250 kg table, fields of view from 5 mm to 500 mm, matrices to 1024, and workflow tools in syngo Inline, AutoAlign and Phoenix that make studies reproducible between operators and visits. Diagnostic interpretation remains with the reporting radiologist. The Tim generation, channel count, coil set and magnet condition are provided by the seller at quotation. Medigear.uk lists the system for UK business buyers and can arrange a siting survey, transport, rigging, installation, staff familiarisation, service cover and the supply of spares and consumables. Enquire for a written quotation.
